Description
Specification：
| Number of Phase | 2 |
| Step Angle |
1.8° |
| Rated Voltage | 3.3 V DC |
| Rated Current |
1.5 Amp |
| Holding Torque |
0.4Nm Typ. (Two-phase on/rated current) |
| Phase resistance | 8.7 ohm±10% (20℃) |
| Phase Inductance | 3.6 mH±20% (1kHz 1V rms) |
| Rotor Inertia | 35 gcm^2 |
| Weight | 0.24 Kg |
| Insulation Class | B(130℃) |
Product Dimensions：
Product Details：
