Description
STEP 2 Fix the screw on the left side of the gantry.
Use screw B that can befound in accessory bag 1
Slide the hotbed to the position ofscrew bolt B, move the gantry sothat the screw bolt A meets screwbolt b of the base(Position can be adjusted until fits.)
Found screw B
Lock the screw into position B
STEP 3 Fix the screws at the bottom of the gantry.
Use screw C in accessory bag 2
Apply foams on the desk, turn theprinter 9o degrees horizontally andplace it on the foam
Take out the screw C in screw bag 2move the wire on the printer by handuntil you find 4 screw bolts c
Lock the screw into position C
STEP 4 Material rack installation
Use screw D in accessory bag 3
Find material rack 13Find material rack 14Find screw C
Install the handing rod into the material rack 14into the direction shown in the figure.
Lock the screw into position D
STEP 5 Fix the material rack on the gantry.
Install the assembled consumablesbracket from top to bottom on the topof the gantry and align the bracketwith the screw hole D of the gantry
Take out the remaining 3 screws Din the screw bag 3 and lock theminto the 3 D positions as shown inthe figure
Non-contact process which is much more safer
Equipped with complete assembly accessories
Ideal v-groove Stable printing
S8 Pro uses V-groove pulleys, smooth movement,low noise, wear proof, and longer life span
Hotbed heating pad S8 Pro Newly added hotbed heating pad
The heating pad heats the platform more evenlywith better printing effect. More convenient todisassemble when printing is completed
Extra Large Printing Size
The s8 Pro has larger printing size comparedto other desktop 3d printers to give you abetter printing experience
Self-researched Mute silent motherboard
Do not cause much distruption norirratation during printing
Independant R&D extra quiet motherboard
Independant R&D extra queit motherboardguarantees smooth printingNoise produced during printing is lower than 55dbPower supply adapts to different voltage of 110V /230V
Smart sensor Resume Printing Function
The machine can automatically resume printingeven during power failure or disconnection.reducing the worries of printing failure
New Knob. Tightener
The XY axis tightener supports adjusting thebelt tighten, which is more convenient to adjustand reduce printing time while printing
